哪吒探针使用教程

官方地址

一个开源、轻量的服务器和网站监控、运维工具

准备条件

1. GitHub账号
2. 服务器一台
3. 域名一个，并已做好解析

如果域名托管到了Cloudflare，记得 tls 设置那里要选择完全/完全（严格），要不然后面反代访问时会报错的

实现目标：用 https://tz.xxx.com 即可访问探针地址

搭建步骤

1. 安装docker，以ubuntu为例

其他版本请参考 这里

apt-get remove docker docker-engine docker.io containerd runc
apt-get update && apt-get install -y ca-certificates curl gnupg lsb-release
mkdir -p /etc/apt/keyrings && curl -fsSL https://download.docker.com/linux/ubuntu/gpg | gpg --dearmor -o /etc/apt/keyrings/docker.gpg && echo "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.gpg] https://download.docker.com/linux/ubuntu $(lsb_release -cs) stable" | tee /etc/apt/sources.list.d/docker.list > /dev/null
apt-get update && apt-get install -y docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin
curl -L https://github.com/docker/compose/releases/download/v2.17.2/docker-compose-`uname -s`-`uname -m` > /usr/local/bin/docker-compose && chmod +x /usr/local/bin/docker-compose

2.创建OAuth Apps

1. 进入这个网址 Developer applications (github.com) ，并点击右上角的 New OAuth App

2. 输入以下信息后，点击 Register application

   Application name	Homepage URL	Authorization callback URL
   随意输入，例如：探针	https://tz.xxx.com	https://tz.xxx.com/oauth2/callback

3. 保存页面中的 Client ID，然后点击 Generate a new client secret，创建一个新的 Client Secret，新建的密钥仅会显示一次，请妥善保存

3.搭建哪吒面板

• 在面板服务器中，运行安装脚本：

curl -L https://raw.githubusercontent.com/naiba/nezha/master/script/install.sh  -o nezha.sh && chmod +x nezha.sh && sudo ./nezha.sh

• 等待脚本跑完后，分别输入以下值：

  • OAuth提供商 - 选择 Github
  • Client ID - 之前保存的 Client ID
  • Client Secret - 之前保存的 Client secrets
  • 用户名 - github用户名，一定要正确的用户名
  • 站点标题 - 自定义站点标题
  • 访问端口 - 公开访问端口，可自定义，默认 8008，反代之后可以不用打开
  • Agent的通信端口 - Agent与Dashboard的通信端口，默认 5555，反代之后一定要打开

• 输入完成后，等待拉取镜像 安装结束后，如果一切正常，此时你可以访问域名+端口号，如 “http://tz.xxx.com:8008” 来查看面板

4.申请ssl证书

1. 安装acme脚本

   apt update && apt install -y cron socat && curl https://get.acme.sh | sh


2. 注册账户

   .acme.sh/acme.sh --register-account -m abcd@qq.com


3. 用80端口申请域名证书，也可以用其他方式

   .acme.sh/acme.sh --issue --standalone -d tz.xxx.com


4. 安装申请好的证书

   [ -d /ssl/tz.xxx.com ] || mkdir -p /ssl/tz.xxx.com
   .acme.sh/acme.sh --installcert -d tz.xxx.com --fullchain-file /ssl/tz.xxx.com/cret.crt --key-file /ssl/tz.xxx.com/private.key
   chmod +r /ssl/tz.xxx.com/cret.crt && chmod +r /ssl/tz.xxx.com/private.key


5. 设置acme脚本自动更新证书

   .acme.sh/acme.sh --upgrade --auto-upgrade


5.设置nginx反向代理

• 创建一个目录，用于存放nginx的docker配置文件

  mkdir /docker/nginx -p


• 配置nginx的docker启动文件

  cd /docker/nginx


  cat > docker-compose.yml <<EOF
  services:
    nginx:
      container_name: nginx
      image: nginx:stable-alpine3.17-slim
      restart: always
      network_mode: "host"
      volumes:
        - /ssl:/ssl:ro
        - ./log:/var/log/nginx
        - ./conf/:/etc/nginx/conf.d/:ro
        - ./html:/usr/share/nginx/html
  EOF


• 配置反代的配置文件

  mkdir conf
  cat > conf/nezha.conf <<\EOF
  server {
          listen  80;
          server_name     tz.xxx.com;
          if ($server_port !~ 443){
                  rewrite ^(/.*)$ https://$host$1 permanent;
          }
  }
  server {
          listen  443 ssl http2;
          server_name     tz.xxx.com;
          #ssl
          ssl_protocols TLSv1.2 TLSv1.3;
          ssl_certificate      /ssl/tz.xxx.com/cret.crt;
          ssl_certificate_key  /ssl/tz.xxx.com/private.key;
          ssl_session_cache    shared:SSL:1m;
          ssl_session_timeout  5m;
          ssl_ciphers  HIGH:!aNULL:!MD5;
          ssl_prefer_server_ciphers  on;
          location / {
              proxy_pass http://172.17.0.1:8008;
              proxy_set_header Host $http_host;
              proxy_set_header      Upgrade $http_upgrade;

          }
          location ~ ^/(ws|terminal/.+)$  {
              proxy_pass http://172.17.0.1:8008;
              proxy_http_version 1.1;
              proxy_set_header Upgrade $http_upgrade;
              proxy_set_header Connection "Upgrade";
              proxy_set_header Host $http_host;
          }
  }
  EOF


• 启动nginx

  docker-compose up -d


• 这时就可以通过访问 https://tz.xxx.com 来访问哪吒面板

美化哪吒

目的：在原探针的基础上美化主题并增加了cpu等信息的显示

步骤如下

1.更改默认主题配置文件

• 进入哪吒的volume数据卷路径

cd `docker inspect dashboard-dashboard-1|grep "/var/lib/docker/overlay2/"|grep MergedDir|grep -oE "/var.*merged"`/dashboard/resource/template/theme-default

• 把原来的文件打包，做一个压缩包

tar -zcf backup.tar.gz ./* && rm -rf home.html

• 下载新的文件

wget https://raw.githubusercontent.com/psmtnhljs/vps-test/main/home.html && wget https://raw.githubusercontent.com/psmtnhljs/vps-test/main/header.html

• 重启面板

docker restart dashboard-dashboard-1

2.更改css

• 登录探针面板后台，将以下代码填入 自定义代码(style、script 都可以) 后保存
• 此处提供一种css，更多主题请自行谷歌寻找，别直接ctrl c+v，自己看着改图片链接

<style>
/* 屏幕适配 */
@media only screen and (min-width: 1200px) {
    .ui.container {
    width: 80% !important;
}
}

@media only screen and (max-width: 767px) {
    .ui.card>.content>.header:not(.ui), .ui.cards>.card>.content>.header:not(.ui) {
        margin-top: 0.4em !important;
    }
}

/* 整体图标 */
i.icon {
    color: #000;
    width: 1.2em !important;
}

/* 背景图片 */
body {
    content: " " !important;
    background: fixed !important;
    z-index: -1 !important;
    top: 0 !important;
    right: 0 !important;
    bottom: 0 !important;
    left: 0 !important;
    background-position: top !important;
    background-repeat: no-repeat !important;
    background-size: cover !important;
/*
每日一图: "https://api.dujin.org/bing/1920.php"
随机风景: "https://api.cyrilstudio.top/bing/image.php/bing?rand=true"
随机动漫: "https://img.xjh.me/random_img.php?type=bg&return=302"
必应: "https://tuapi.eees.cc/api.php?category=biying&type=302"
*/
    background-image: url(https://bing.yuji2022.tk/?rand=true) !important;
    font-family: Arial,Helvetica,sans-serif !important;
}

/* 导航栏 */
.ui.large.menu {
    border: 0 !important;
    border-radius: 0px !important;
    background-color: rgba(255, 255, 255, 55%) !important;
}

/* 首页按钮 */
.ui.menu .active.item {
    background-color: transparent !important;
}

/* 导航栏下拉框 */
.ui.dropdown .menu {
    border: 0 !important;
    border-radius: 0 !important;
    background-color: rgba(255, 255, 255, 80%) !important;
}

/* 登陆按钮 */
.nezha-primary-btn {
    background-color: transparent !important;
    color: #000 !important;
}

/* 大卡片 */
#app .ui.fluid.accordion {
    background-color: #fbfbfb26 !important;
    border-radius: 1rem !important;
}

/* 小卡片 */
.ui.four.cards>.card {
    border-radius: 1rem !important;
    background-color: #fafafaa3 !important;
}

.status.cards .wide.column {
    padding-top: 0 !important;
    padding-bottom: 0 !important;
    height: 3.3rem !important;
}

.status.cards .three.wide.column {
    padding-right: 0rem !important;
}

.status.cards .wide.column:nth-child(1) {
    margin-top: 2rem !important;
}

.status.cards .wide.column:nth-child(2) {
    margin-top: 2rem !important;
}

.status.cards .description {
    padding-bottom: 0 !important;
}

/* 小鸡名 */
.status.cards .flag {
    margin-right: 0.5rem !important;
}

/* 弹出卡片图标 */
.status.cards .header > .info.icon {
    margin-right: 0 !important;
}

.nezha-secondary-font {
    color: #21ba45 !important;
}

/* 进度条 */
.ui.progress {
    border-radius: 50rem !important;
}
.ui.progress .bar {
    min-width: 1.8em !important;
    border-radius: 15px !important;
    line-height: 1.65em !important;
    color:black
}
.ui.fine.progress> .bar {
    background-color: #ba45ac !important;
}
.ui.progress> .bar {
    background-color: #000 !important;
}

.ui.progress.fine .bar {
    background-image: linear-gradient(120deg, #d4fc79 0%, #96e6a1 100%);!important;
}

.ui.progress.warning .bar {
    background-image: linear-gradient(to right, #fa709a 0%, #fee140 100%); !important;
}

.ui.progress.error .bar {
    background-image: linear-gradient(to top, #ff0844 0%, #ffb199 100%);important;
}

.ui.progress.offline .bar {
    background-image: linear-gradient(to top, #e6e9f0 0%, #eef1f5 100%); !important;
}

/* 上传下载 */
.status.cards .outline.icon {
    margin-right: 1px !important;
}

i.arrow.alternate.circle.down.outline.icon {
    color: #21ba45 !important;
}

i.arrow.alternate.circle.up.outline.icon {
    color: red !important;
}

/* 弹出卡片小箭头 */
.ui.right.center.popup {
    margin: -3px 0 0 0.914286em !important;
    -webkit-transform-origin: left 50% !important;
    transform-origin: left 50% !important;
}

.ui.bottom.left.popup {
    margin-left: 1px !important;
    margin-top: 3px !important;
}

.ui.top.left.popup {
    margin-left: 0 !important;
    margin-bottom: 10px !important;
}

.ui.top.right.popup {
    margin-right: 0 !important;
    margin-bottom: 8px !important;
}

.ui.left.center.popup {
    margin: -3px .91428571em 0 0 !important;
    -webkit-transform-origin: right 50% !important;
    transform-origin: right 50% !important;
}

.ui.right.center.popup:before,
.ui.left.center.popup:before {
    border: 0px solid #fafafaeb !important;
    background: #fafafaeb !important;
}
.ui.top.popup:before {
    border-color: #fafafaeb transparent transparent !important;
}

.ui.popup:before {
    border-color: #fafafaeb transparent transparent !important;
}

.ui.bottom.left.popup:before {
    border-radius: 0 !important;
    border: 1px solid transparent !important;
    border-color: #fafafaeb transparent transparent !important;
    background: #fafafaeb !important;
    -webkit-box-shadow: 0px 0px 0 0 #fafafaeb !important;
    box-shadow: 0px 0px 0 0 #fafafaeb !important;
    -webkit-tap-highlight-color: rgba(0,0,0,0) !important;
}

.ui.bottom.right.popup:before {
    border-radius: 0 !important;
    border: 1px solid transparent !important;
    border-color: #fafafaeb transparent transparent !important;
    background: #fafafaeb !important
    -webkit-box-shadow: 0px 0px 0 0 #fafafaeb !important;
    box-shadow: 0px 0px 0 0 #fafafaeb !important;
    -webkit-tap-highlight-color: rgba(0,0,0,0) !important;
}

.ui.top.left.popup:before {
    border-radius: 0 !important;
    border: 1px solid transparent !important;
    border-color: #fafafaeb transparent transparent !important;
    background: #fafafaeb !important;
    -webkit-box-shadow: 0px 0px 0 0 #fafafaeb !important;
    box-shadow: 0px 0px 0 0 #fafafaeb !important;
    -webkit-tap-highlight-color: rgba(0,0,0,0) !important;
}

.ui.top.right.popup:before {
    border-radius: 0 !important;
    border: 1px solid transparent !important;
    border-color: #fafafaeb transparent transparent !important;
    background: #fafafaeb !important;
    -webkit-box-shadow: 0px 0px 0 0 #fafafaeb !important;
    box-shadow: 0px 0px 0 0 #fafafaeb !important;
    -webkit-tap-highlight-color: rgba(0,0,0,0) !important;
}

.ui.left.center.popup:before {
    border-radius: 0 !important;
    border: 1px solid transparent !important;
    border-color: #fafafaeb transparent transparent !important;
    background: #fafafaeb !important;
    -webkit-box-shadow: 0px 0px 0 0 #fafafaeb !important;
    box-shadow: 0px 0px 0 0 #fafafaeb !important;
    -webkit-tap-highlight-color: rgba(0,0,0,0) !important;
}

/* 弹出卡片 */
.status.cards .ui.content.popup {
    min-width: 20rem !important;
    line-height: 2rem !important;
    border-radius: 1rem !important;
    border: 1px solid transparent !important;
    background-color: #fafafaeb !important;
    font-family: Arial,Helvetica,sans-serif !important;
}

.ui.content {
    margin: 0 !important;
    padding: 1em !important;
}

/* 服务页 */
.ui.table {
    background: RGB(225,225,225,0.6) !important;
}

.ui.table thead th {
    background: transparent !important;
}

/* 服务页进度条 */

/* 版权 */
.ui.inverted.segment, .ui.primary.inverted.segment {
    color: #000 !important;
    font-weight: bold !important;
    background-color: #fafafaa3 !important;
}
</style>

<script>
    window.onload = function(){
    var avatar=document.querySelector(".item img")
    var footer=document.querySelector("div.is-size-7")
    document.querySelector("[rel='shortcut icon']").href = "https://s1.yesimg.com/2022/d2087fb7236f3.png"
    footer.innerHTML="うずまきナルトのクラウドサーバー"
    footer.style.visibility="visible"
    avatar.src="https://s1.yesimg.com/2022/d2087fb7236f3.png"
    avatar.style.visibility="visible"
    }
</script>

哪吒数据的备份

1. 停止原来的哪吒
2. 把旧哪吒的数据备份到新哪吒即可，数据目录在 /opt/nezha/ ，也就是把这个目录原封不动地拷贝过去既可以了
3. 进入新哪吒的网页端后台，设置 未接入CDN的面板服务器域名/IP ，只有这个设置对了，才能迁移成功。
4. 未接入CDN的面板服务器域名/IP 这个设置如果用域名的话，不能开CDN

哪吒的其他设置

略

Q.E.D.
